Product Description
The VEGA-10G includes all the basic components of hardware, design tools enabling a complete embedded processing platform and transceiver based designs including PCIe. The included pre-verified reference designs and industry-standard FPGA Mezzanine Connectors (FMC) allow scaling and customization with daughter cards. OS platform PetaLinux.
Key Features & Benefits
- Optimized for quickly prototyping embedded applications using Zynq-7030 SoCs, Compatible with 7045
- Hardware, design tools, IP, and pre-verified reference designs
- Demonstrates a embedded design, targeting video pipeline
- Advanced memory interface with
- DDR3 Component Memory 1GB (PS)
- DDR3 SODIM Memory 1GB (PL)
- IIC - 1 KB EEPRO
- 32GB on Board eMMC
- Enabling serial connectivity with PCIe Gen2x4, SFP+ and SMA Pairs, USB OTG, UART, IIC
- Supports embedded processing with Dual ARM Cortex-A9 core processors
- Develop networking applications with 10-100-1000 Mbps Ethernet (RGMII)
- Implement Video display applications with HDMI out
- Expand I/O with the FPGA Mezzanine Card (FMC) interface
- OS platform PetaLinux.
